Performance Specifications
| Parameter |
Premium |
|
Operating Wavelength (nm) |
1460 ~ 1610 |
|
Typical Peak Isolation (dB) |
50 |
|
Minimum Isolation(@23°C, SOP*) (dB) |
>45 |
| Minimum Isolation(@0~+60°C, SOP*) (dB) |
>40 |
|
Typical Insertion Loss(@0~+60°C, SOP*)** (dB) |
0.60 |
|
Maximum Insertion Loss(@0~+60°C, SOP*)** (dB) |
0.90 |
|
Return Loss (In/Out) (dB) |
60/55 |
|
PDL (dB) |
0.1 |
| PMD (ps) |
0.05 |
|
Operating Temperature (°C) |
-20 to + 70 |
|
Storage Temperature (°C) |
-40 to +85 |
|
Fiber Type |
250um bare fiber or 900um tight buffer |
|
Fiber Length (Min.) |
1 meter |
|
Package Dimension (mm) |
F5.5xL34,F3.0x25 |
|
Power Handling(MW) |
300 |
* SOP: All states of polarization
** Does not include connector, splice and fiber-end fresnel losses
Ordering Information
|
|
|
|
|
|
|
|
Isolator Type |
Wavelength |
Pigtail Style |
Fiber Length |
Package |
In/Out Connector |
|
IU=Dual Stage
|
SCL=S, C and LBand |
1=Bare Fiber
2=900um Jacket
|
1=1.0m
2=1.5m
3=2.0m
4=Custom Length |
B=Package B |
0=None
1=FC/APC
2=FC/PC
3=SC/APC
4=SC/PC
5=ST
6=LC | |
