| Features ApplicationsLow Insertion LossLow Polarization SensitivityOptical Path Epoxy Free Fiberoptic AmplifiersCATV Fiberoptics LinksFiberoptic Testing SystemsFiberoptic LAN SystemsTelecommunications

Performance Specifications
ParameterSpecificationOperating Wavelength (nm)1310, 1480 or 1550Operating Bandwidth (nm)±40Max. Insertion loss (dB)*See table belowMin. PDL (dB)0.05Optical Power Hunding (mW)300Max. Tenile Load (N)5Operation Temperature (°C)-5 ~ +70Fiber TypeSMF-28Dimensions (mm)F3.2x12mm
Percentage (%)Insertion Loss (dB)990.20980.25970.30960.35950.40
Ordering InformationFMRWavelengthPercentagePigtail StyleFiber LengthDimensionIn/Out Connector13=1310nm14=1480nm15=1550nm35=1310/1550nm99=99%98=98%97=97%1=Bare Fiber2=900um Jacket1=1m2 =1.5m3=2m4 =Custom lengthA=F3.2x12mm B=Customized0=None1=FC/APC2=FC/PC3=SC/APC4=SC/PC5=ST6=LC |
|


Packaging & Labeling |
To protect each of product, Fiberer will use firm and secure Package, and common use Fiberer Label if customer not remark.
It is available to use custmized labeling and packaging for customer request.
|
Shipment |
All shipment will be succssful to arrive customer's address. Fiberer try our best to let the shipment fast for customers, and the common express is by air of Fedex, DHL, UPS, EMS and TNT.
If the customer pay Fiberer the shipment charge, it will use Fiberer express account for the shipment, otherwise it need to use the customer's express account. |
Customized & OEM |
| Fiberer always do Customized for customer's request successfully, It is available for Customized & OEM. |
